Sliding Gate Wheel with Interior Bracket
Sliding gate wheels supplied in an interior bracket, 26 catalogue models from 48 to 118 mm wheel diameter in V, U and Y groove, single or double bearing.
Need a Quote?
For pricing, drawings, lead time and technical support, please contact our sales team.
- ✓ OEM & Custom Manufacturing
- ✓ Technical Drawing Support
- ✓ Fast Delivery
- ✓ Worldwide Shipping
Sliding gate wheels in an interior bracket: 26 catalogue models, 48 to 118 mm wheel diameter, V, U and Y groove.
How It Mounts
The wheel is carried in an interior bracket that sits within the line of the gate frame. C1 models use a single bearing; C2 models use a double bearing.
Groove Profiles
Each style is catalogued in three groove profiles. The groove must match the track: a V-groove wheel runs on an inverted angle iron track, a U-groove wheel on a round bar track. Y-groove wheels are drawn with a 92° included groove angle in our catalogue. If you are not sure which profile your track needs, send a photograph of the track section and we will match it.
Catalogue Models
A is the wheel diameter and B the wheel width. C and D are the bracket dimensions shown on the catalogue drawing, available on request. Weight is per wheel assembly.
| Model | Groove | Bearing | A (mm) | B (mm) | C (mm) | D (mm) | Weight (kg) | Pcs/ctn |
|---|---|---|---|---|---|---|---|---|
| C1Y50 | Y | Single | 48 | 15 | 26 | 100 | 0.25 | 50 |
| C1Y60 | Y | Single | 58 | 17 | 26 | 100 | 0.36 | 50 |
| C1Y70 | Y | Single | 68 | 20 | 33 | 135 | 0.58 | 30 |
| C1Y80 | Y | Single | 78 | 20 | 33 | 135 | 0.75 | 30 |
| C1Y90 | Y | Single | 88 | 20 | 33 | 152 | 1.05 | 15 |
| C1Y100 | Y | Single | 98 | 20 | 33 | 152 | 1.2 | 15 |
| C1Y120 | Y | Single | 118 | 25 | 36 | 201 | 2.8 | 10 |
| C2Y70 | Y | Double | 68 | 23 | 33 | 135 | 0.68 | 30 |
| C2Y80 | Y | Double | 78 | 23 | 33 | 135 | 0.85 | 30 |
| C2Y90 | Y | Double | 88 | 24 | 33 | 152 | 1.2 | 15 |
| C2Y100 | Y | Double | 98 | 24 | 33 | 152 | 1.4 | 15 |
| C2Y120 | Y | Double | 118 | 25 | 36 | 201 | 2.2 | 10 |
| C1V50 | V | Single | 48 | 15 | 26 | 100 | 0.25 | 50 |
| C1V60 | V | Single | 58 | 17 | 26 | 100 | 0.36 | 50 |
| C1V70 | V | Single | 68 | 20 | 33 | 135 | 0.58 | 30 |
| C1V80 | V | Single | 78 | 20 | 33 | 135 | 0.75 | 30 |
| C1V90 | V | Single | 88 | 20 | 33 | 152 | 1.05 | 15 |
| C1V100 | V | Single | 98 | 20 | 33 | 152 | 1.2 | 15 |
| C1V120 | V | Single | 118 | 25 | 36 | 201 | 2.18 | 10 |
| C1U50 | U | Single | 48 | 15 | 26 | 100 | 0.24 | 50 |
| C1U60 | U | Single | 58 | 17 | 26 | 100 | 0.36 | 50 |
| C1U70 | U | Single | 68 | 20 | 33 | 135 | 0.56 | 30 |
| C1U80 | U | Single | 78 | 20 | 33 | 135 | 0.73 | 30 |
| C1U90 | U | Single | 88 | 20 | 33 | 152 | 1 | 15 |
| C1U100 | U | Single | 98 | 20 | 33 | 152 | 1.15 | 15 |
| C1U120 | U | Single | 118 | 25 | 36 | 201 | 2.15 | 10 |
Information to Include with an Enquiry
- Track profile and size: angle iron size, round bar diameter, or a section photograph with a ruler.
- Gate weight and number of wheels.
- Mounting: bolted through the frame, bracket welded under the frame, or plate.
- Clearance available under the gate frame.
- Model number if you are replacing an existing wheel.
Related: sliding gate gear racks and our guide to choosing a sliding gate wheel. Dimensioned drawings are available on request.
| Brand | KDI |
|---|---|
| Model | KDI-SGW-C |
| Product Type | Sliding gate wheel with interior bracket |
